Centrifugal pumps
Type series WSCA
Standardized electric centrifugal pump made of stainless steel AISI304. Very robust construction. Hydroforming process.
Materials
- Pump housing and housing cover: Stainless steel AISI304
- Impeller: Stainless steel AISI304
- Standard mechanical seal: Carbon/Ceramic/NBR
- Special mechanical seals available on request
Pumping media
Clean water and lightly polluted liquids.
Drive
Low noise IEC norm three phase motor in efficiency class IE 2 oder IE 3. Other executions or mountings available on request.
Technical details
Operating data
| Flow rate | Q | up to 4.000 m³/h |
| Delivery height | H | up to 98 m |
| Medium temperature | t | -10 °C up to +120 °C |
| Operating pressure | p | up to 10 bar |
Other operating conditions possible on request!
